Specifications

Image Sensor: 1/3" Sony Super HAD CCD
Effective Pixels: 811H x 508V
Total Pixels: 768H x 494V
Scanning System: 2:1 Interlaced 525 TV Lines
Scanning Frequency: 15,734KHz (H) / 59.94Hz
Shutter Speed: 1/60 ~ 1/100,000sec.
Sync. System: Internal
Resolution: 650 TV-Lines
White Balance: ATW
Backlight Compensation: On / Off
Flickerless: On / Off
AGC: On / Off
Video Output: 1.0 Vp-p Composite Video (75Ω load)
S/N Ratio: 45dB
Min. Illumination: 0 Lux for Infrared Lighting Conditions
IR Range: 60ft
Iris Control: Auto
LED Quantity: 24 pcs
Gamma Characteristic: r=0.45
Lens: 2.8mm~12mm Vari-Focal
Operating Temp.: -10 ~ +50°C
Power Consumption: DC 12V 110mA (CDS On: 420mA)
Dimensions: 4.8(Φ) x 3.9(H) Inch (approx.)
Weight: 1.8 lbs (approx.)

*Above specifications and design subject to change without notification
