Specifications

Image Sensor: 1/3" Interline CCD
Effective Pixels: 512(H) x 492(V)
H. Resolution: 420 TV line
Min. Illumination: 0.02 Lux, F:2.0
Synchronizing System: Internal
Scanning System: 525 line, 60 field/sec
Video Output: 1.0Vp-p composite, 75Ω
S/N Ratio: More than 48 dB (AGC off)
Electronic Shutter: 1/60~100,000 sec
Gamma Correction: γ=0.45
Lens: 3.6mm fixed lens
Power Source: DC 12V (±10%)
Operation Temperature: -40°C~50°C RH 95% Max
Preservation Temperature: -40°C~60°C RH 95% Max
Power Consumption: 100mA
Dimensions: 0.9Φ x 2 inch
Case Material: Aluminum

*Above specifications and design subject to change without notification
