Specifications

Image Sensor: 1/4” Sharp CCD
Effective Pixels: 510(H) x 492(V)
H. Resolution: 420 TV line
Min. Illumination: 0.5 Lux
Synchronizing System: Internal
Scanning System: 2:1 interlace
Video Output: 1.0Vp-p composite, 75Ω
S/N Ratio: More than 46 dB (AGC off)
Electronic Shutter: 1/60~100,000 sec
Gamma Correction: r=0.45
Lens: 4mm fixed lens
Power Source: DC 12V (± 10%)
Operation Temperature: -10°C~50°C RH 95% Max
Preservation Temperature: -21°C~60°C RH 95% Max
Power Consumption: 90mA
Dimensions: 0.9Ø x 3.3 inch

*Above specifications and design subject to change without notification
