Specifications

Camera
Image Sensor: 1/3" Progressive Scan CMOS
Signal System: NTSC
Min. Illumination: 0.07Lux @(F1.2,AGC ON), 0 Lux with IR | 0.1Lux @(F1.4,AGC ON), 0 Lux with IR
Shutter time: 1/3 s to 1/100,000 s
Lens: 2.8 - 12 mm @ F1.4, Angle of view: 91.2°-28.3°
Lens Mount: φ14
Adjustment Range: Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355°
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: Digital WDR
Digital noise reduction: 3D DNR

Compression Standard
Video Compression: H.264/MJPEG
Video bit rate: 32Kbps~12Mbps
Audio Compression: None
Dual Stream: Yes

Max. Image Resolution: 2048×1536
Frame Rate: 50Hz: 20fps (2048 × 1536), 25fps (1920 × 1080), 25fps (1280 × 720) | 60Hz: 20fps (2048 × 1536), 30fps (1920 × 1080), 30fps (1280 × 720)
Image Settings: Saturation, brightness, contrast adjustable through client software or web browser
BLC: Yes, zone configurable
ROI: Support

Network
Network Storage: NAS (Support NFS,SMB/CIFS)
Alarm Trigger: Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6,B onjour
Security: User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask
System Compatibility: ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI

Interface
Communication Interface: 1 RJ45 10M / 100M Ethernet interface
On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button: Yes

General
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F), Humidity 95% or less (non-condensing)
Power Supply: 12 VDC ± 10%, PoE (802.3af)
Power Consumption: Max. 5.5 W
Impact Protection: IEC60068-2-75Eh, 50J; EN50102, IK10
Weather Proof: IP66
IR Range: Up to 30m
Dimensions: Φ 140 × 99.9 mm (Φ 5.51” × 3.94”)
Weight: 1000g

*Above specifications and appearance of product subject to change any time
