System
Main Processor: Dual-core embedded processor
Operating System: Embedded LINUX
Video & Audio
IP Camera Input: 32 channel
Two-way Talk: 1channel Input, 1channel Output, RCA
Display
Interface: 2 HDMI,1 VGA
Resolution: 3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split: 1/4/8/9/16
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression: H.265/H.264/MJPEG
Resolution: 12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P & etc.
Record Rate: Max 192Mbps
Bit Rate: 1~ 20Mbps
Record Mode: Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval: 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger Events: Recording, PTZ, Tour, Alarm, Video Push, Email,FTP, Buzzer & Screen tips
Video Detection: Motion Detection,MD Zones: 396(22×18), Video Loss & Camera Blank
Playback & Backup
Sync Playback: 1/4/9/16
Search Mode: Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode: USB Device/Network/Internal SATA burner/eSATA Device
Network
Ethernet: 2 RJ-45 port (10/100/1000Mbps)
PoE: 16 ports (IEEE802.3af)
Network Function: HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.)
Max. User Access: 128 users
Smart Phone: iPhone, iPad, Android, Windows Phone
Storage
Internal HDD: 4 SATA III ports, up to 24TB
External HDD: 1 eSATA port
Auxiliary Interface
USB: 3 ports (2 Rear USB3.0, 1 Front USB2.0)
RS232: 1 port, For PC communication& Keyboard
RS485: 1 port, For PTZ control
General
Power Supply: Single, AC 100~240V, 50/60 Hz
Power Consumption: 26.5W (without HDD) | max 25W for each PoE port, 150W total
Working Environment: -10°C~+55°C / 10%~90%RH / 86~106kpa
Dimension(W×D×H): 1.5U, 440mm×413mm×75mm
Weight: 465KG (without HDD)
*Above specifications and design subject to change without notification
