System
Main Processor: Dual-core embedded processor
Operating System: Embedded LINUX
Video & Audio
IP Camera Input: 4 channel
Two-way Talk: 1channel Input, 1channel Output, RCA
Display
Interface: 1 HDMI,1 VGA
Resolution: 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split: 1/4
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression: H.264/MJPEG
Resolution: 1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480) & etc
Record Rate: Max 56Mbps
Bit Rate: 48~ 8192kbps
Record Mode: Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval: 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger Events: Recording, PTZ, Tour, Alarm, Video Push, Email,FTP, Buzzer & Screen tips
Video Detection: Motion Detection,MD Zones: 396(22×18), Video Loss & Camera Blank
Playback & Backup
Sync Playback: 1/4
Search Mode: Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode: USB Device/Network/Internal SATA burner
Network
Ethernet: 1 RJ-45 port (10/100Mbps)
PoE: 4 ports (IEEE802.3af)
Network Function: HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.), SNMP, P2P
Max. User Access: 128 users
Smart Phone: iPhone, iPad, Android, Windows Phone
Storage
Internal HDD: 1 SATA port, up to 4TB
Auxiliary Interface
USB: 2 ports (Rear) USB2.0
General
Power Supply: Single, DC48V/1.25A
Power Consumption: NVR: 10W(without HDD) | PoE: Max.25.5W for single port
Working Environment: -10°C~+55°C / 10%~90%RH / 86~106kpa
Dimension(W×D×H): Smart 1U, 205mm×205mm×45mm
Weight: 500g(without HDD)
*Above specifications and design subject to change without notification
