Specifications

Video Encoding:
H.264/MJPEG(simultaneous dual stream)
H.264/H.264 (true H.264 dual streaming)
Simultaneous streaming with independent control

Resolution: 1920x1080, 1280x720, 640x352, 320x176, 160x96

Live Casting: Streaming video channels
              Up to max 30fps@ 2M when simplex

Serial Interface: Console, By-pass command to control UART device
                  Serial Input/Output mode ( 3.3V TTL )

Bandwidth Management: Frame rate control / Bandwidth control / CBR / VBR
Alarm Management: [ Trigger Condition ] Video loss / Video recovered / Motion detection (144 area) / Boot finished /  Schedule
                  [ Alarm Service ] Image holding service (Max 5.6MByte pre-post alarm buffer), Image upload service through
                                    E-mail / FTP (support pre & post), Notification service through TCP / UDP / HTTP

Security: Channel based user password protection for live-cast, PTZ, alarm output and audio
Dynamic IP: Dynamic IP service using www.ipcctvdns.com
Smart Solution: Smart Phone Application (IOS, Android)

Web interface: Live-cast, PTZ control, search through Web browser
               Minimum PC requirement - Windows XP Pro (IE 6.x or later) , Pentium4 (2Ghz, 2G RAM), Video Card(256MB RAM,
                                        1024x768)

Management Software: Supports 16, 32, 64, 128ch Management Software
                     Full-featured PC NVR with matrix functionality

System Integration:
[ Protocol ] HTTP, RTP/RTSP, TCP/IP, FTP, Telnet, RARP, PPPoE, SNMP, PAP, CHAP, DHCP, NTP, SMTP client, uPNP, and etc.
[ SDK ] Open HTTP API / ActiveX for live cast with audio & PTZ
[ Service ] Image upload / notification service / service for POS integration

Installation & maintenance: Configuration by installation wizard, HTTP, telnet and console.
                            Upgrade firmware through HTTP, telnet & FTP

Misc.: Transmit serial input data with video
       Quick Time & VLC media player compatible

System hardware: 32bit Embedded CPU / Embedded Linux / 128MByte SDRAM / 128MByte NAND Flash

Power: Power Supply - SMPS 12V (1A) [AC100~240V, 50/60Hz, 300mA]
                      Max. Power Consumption - DC12V, 5.4W

Approvals: IP66, KC, FCC, CE, RoHS

Dimension / Weight: 68 Ø x 258.3(L) (in mm) without sunshield
                    About 669g without power supply

External Interface: 10/100-Base-T Ethernet (auto-sensing)
                    1 DI/DO(3.3V TTL)
                    1 UART port(3.3V TTL)
                    Factory Default Button

Working Environment: Temperature: -10~50 ℃, Humidity: 10~90% RH

Image sensor: 1/2.9” progressive scan CMOS
              Total number of pixels: 2000H×1241V=2.48M
              Pixel size : 2.5 8 (H) μm × 2.5 8 (V) μm
              Color filter Bayer arrangement of primary colors: R, G, B
              Bit number of internal ADC: 10/12 bits
              Parallel output: 37.125 MHz, 10/12 bits
              Maximum frame rate in all-pixel scan mode: 60/30 fps

Lens: 2.8-10mm, V/F, F1.2

Image Setting: Day & Night  (Auto/B&W/Off)
               Auto White Balance
               Noise Filter (Off/On)
               Brightness/Contrast/Sharpness/AGC Gain Control
               Lens Type (DC/Manual)
               Shutter (Manual/Auto)
               Vertical/Horizontal Flip
               Sens Up Level
               Frequency Control (50/60)

Minimum illumination: 0 Lux (IR)
Options: Built-in PoE (IEEE 802.3af)

*Above specifications and design subject to change without notification
